6H30B Hydraulic Knee Joint

The 6Н30B hydraulic knee joint is engineered for individuals with transfemoral amputations, supporting users up to 150 kg. Designed for high-activity users, it delivers a smooth, controlled, and confident walking experience across a variety of environments—including water. Key Features 💧 Waterproof Design Built for reliability in wet and aquatic environments, giving users the freedom to move without limitations. 🔒 Safety Lock Mechanism A mechanical lock in full extension provides added stability and security when standing or walking. ⚙️ Hydraulic Control System The rotary hydraulic unit ensures:

• Smooth and controlled swing phase
• Strong, stable support during the stance phase

🚶 Natural Gait Performance Optimized for walking on:

• Stairs
• Slopes and inclines The system closely replicates a physiological gait pattern for more natural movement.

➕ Extension Assist Option Increase extension assist force with an additional spring (included in the package). Design Options Available in Red and Blue to match personal style preferences Technical Characteristics

Material	Aluminum alloy
Weight	1,2 kg
Max. weight of patient	150 kg
Build height	176 mm
Knee flexion	150°
Temperature range	–10 … +40°С
